SVHN 图像分类实验报告

from torchvision import transforms

# 训练集数据增强
train_transform = transforms.Compose([
    transforms.RandomCrop(32, padding=4),      # 随机裁剪
    transforms.RandomHorizontalFlip(),          # 水平翻转
    transforms.RandomRotation(10),              # 随机旋转±10°
    transforms.ColorJitter(brightness=0.2, contrast=0.2),  # 颜色抖动
    transforms.ToTensor(),                       # 转换为Tensor
    transforms.Normalize(                        # SVHN标准化参数
        mean=[0.4377, 0.4438, 0.4728],
        std=[0.1980, 0.2010, 0.1970]
    )
])

# 测试集预处理
test_transform = transforms.Compose([
    transforms.ToTensor(),
    transforms.Normalize(
        mean=[0.4377, 0.4438, 0.4728],
        std=[0.1980, 0.2010, 0.1970]
    )
])

import torch
import torch.nn as nn
import torchvision.models as models

class SVHNDenseNet(nn.Module):
    """
    DenseNet-121 适配器 - 针对SVHN 32x32图像优化

    DenseNet核心特点：
    1. 密集连接：每一层都与后续所有层连接
    2. 特征复用：前面层的特征被后面层直接使用
    3. 参数量少：相比ResNet，参数量更少
    4. 梯度流通：梯度可直接传回前面层
    """
    def __init__(self, num_classes=10):
        super().__init__()
        # 加载预训练DenseNet-121权重
        self.densenet = models.densenet121(weights=models.DenseNet121_Weights.IMAGENET1K_V1)
        # 修改首层卷积：适配32x32小图像
        self.densenet.features.conv0 = nn.Conv2d(
            3, 64, kernel_size=3, stride=1, padding=1, bias=False
        )
        # 移除首层最大池化（避免过早缩小32x32图像）
        self.densenet.features.pool0 = nn.Identity()
        # 修改分类器：适配SVHN 10类
        self.densenet.classifier = nn.Linear(1024, num_classes)
        # 初始化分类器权重
        nn.init.xavier_uniform_(self.densenet.classifier.weight)
        nn.init.zeros_(self.densenet.classifier.bias)

    def forward(self, x):
        return self.densenet(x)

def rand_bbox(size, lam):
    """生成CutMix的随机裁剪区域"""
    W, H = size[2], size[3]
    cut_rat = torch.sqrt(1. - lam)
    cut_w, cut_h = int(W * cut_rat), int(H * cut_rat)
    cx, cy = torch.randint(0, W, (1,)).item(), torch.randint(0, H, (1,)).item()
    bbx1, bby1 = max(0, cx - cut_w // 2), max(0, cy - cut_h // 2)
    bbx2, bby2 = min(W, cx + cut_w // 2), min(H, cy + cut_h // 2)
    return bbx1, bby1, bbx2, bby2

def cutmix_data(x, y, alpha=1.0):
    """
    CutMix: 通过裁剪拼接混合两个样本
    不同于MixUp的线性混合，CutMix保留局部区域特征
    """
    lam = torch.distributions.Beta(alpha, alpha).sample()
    index = torch.randperm(x.size(0)).to(x.device)
    bbx1, bby1, bbx2, bby2 = rand_bbox(x.size(), lam)
    x[:, :, bbx1:bbx2, bby1:bby2] = x[index, :, bbx1:bbx2, bby1:bby2]
    lam = 1 - ((bbx2 - bbx1) * (bby2 - bby1) / (x.size(-1) * x.size(-2)))
    return x, y, y[index], lam

def cutmix_criterion(criterion, pred, y_a, y_b, lam):
    """CutMix损失函数: 按比例组合两个样本的损失"""
    return lam * criterion(pred, y_a) + (1 - lam) * criterion(pred, y_b)

"""
SVHN 图像分类器训练脚本
基于PyTorch + GPU 加速的深度学习实验

【实验设计】
- 数据集: SVHN (街景门牌号, 彩色32x32, 10类)
- 模型: DenseNet-121 (密集连接卷积网络)
- 数据增强: CutMix (裁剪拼接增强)
- 学习率调度: OneCycleLR (单周期学习率)
- 优化器: AdamW (带权重衰减的Adam)
"""

import os
import time
import logging
import glob
import re
from datetime import datetime

import torch
import torch.nn as nn
import torch.optim as optim
from torch.utils.data import DataLoader
from torchvision import transforms
from torchvision.datasets import SVHN
import torchvision.models as models


def create_date_output_dir(base_dir='.'):
    """创建当天日期的输出目录"""
    today = datetime.now()
    date_str = today.strftime('%Y-%m-%d')
    dir_name = os.path.join(base_dir, date_str)
    if not os.path.exists(dir_name):
        os.makedirs(dir_name, exist_ok=True)
        return dir_name
    counter = 1
    while True:
        dir_name_with_suffix = os.path.join(base_dir, f"{date_str}_{counter}")
        if not os.path.exists(dir_name_with_suffix):
            os.makedirs(dir_name_with_suffix, exist_ok=True)
            return dir_name_with_suffix
        counter += 1


def get_device():
    """自动检测并选择最佳计算设备"""
    if torch.cuda.is_available():
        device = torch.device("cuda")
        print(f"[GPU] 使用CUDA设备: {torch.cuda.get_device_name(0)}")
    elif torch.backends.mps.is_available():
        device = torch.device("mps")
    else:
        device = torch.device("cpu")
    return device


def rand_bbox(size, lam):
    """生成CutMix的随机裁剪区域"""
    W, H = size[2], size[3]
    cut_rat = torch.sqrt(1. - lam)
    cut_w, cut_h = int(W * cut_rat), int(H * cut_rat)
    cx, cy = torch.randint(0, W, (1,)).item(), torch.randint(0, H, (1,)).item()
    bbx1, bby1 = max(0, cx - cut_w // 2), max(0, cy - cut_h // 2)
    bbx2, bby2 = min(W, cx + cut_w // 2), min(H, cy + cut_h // 2)
    return bbx1, bby1, bbx2, bby2


def cutmix_data(x, y, alpha=1.0):
    """CutMix: 通过裁剪拼接混合两个样本"""
    lam = torch.distributions.Beta(alpha, alpha).sample()
    index = torch.randperm(x.size(0)).to(x.device)
    bbx1, bby1, bbx2, bby2 = rand_bbox(x.size(), lam)
    x[:, :, bbx1:bbx2, bby1:bby2] = x[index, :, bbx1:bbx2, bby1:bby2]
    lam = 1 - ((bbx2 - bbx1) * (bby2 - bby1) / (x.size(-1) * x.size(-2)))
    return x, y, y[index], lam


def cutmix_criterion(criterion, pred, y_a, y_b, lam):
    """CutMix损失函数"""
    return lam * criterion(pred, y_a) + (1 - lam) * criterion(pred, y_b)


class SVHNDenseNet(nn.Module):
    """DenseNet-121 适配器 - 针对SVHN 32x32图像优化"""
    def __init__(self, num_classes=10):
        super().__init__()
        self.densenet = models.densenet121(weights=models.DenseNet121_Weights.IMAGENET1K_V1)
        self.densenet.features.conv0 = nn.Conv2d(3, 64, kernel_size=3, stride=1, padding=1, bias=False)
        self.densenet.features.pool0 = nn.Identity()
        self.densenet.classifier = nn.Linear(1024, num_classes)
        nn.init.xavier_uniform_(self.densenet.classifier.weight)
        nn.init.zeros_(self.densenet.classifier.bias)

    def forward(self, x):
        return self.densenet(x)


def train_one_epoch(model, train_loader, criterion, optimizer, device, epoch, scheduler=None, use_cutmix=True, cutmix_alpha=1.0):
    """训练一个epoch"""
    model.train()
    running_loss, correct, total = 0.0, 0, 0
    for batch_idx, (data, target) in enumerate(train_loader):
        data, target = data.to(device), target.to(device)
        optimizer.zero_grad()
        if use_cutmix:
            data, target_a, target_b, lam = cutmix_data(data, target, alpha=cutmix_alpha)
            outputs = model(data)
            loss = cutmix_criterion(criterion, outputs, target_a, target_b, lam)
            _, predicted = outputs.max(1)
            total += target.size(0)
            correct += (lam * predicted.eq(target_a).sum().float() + (1 - lam) * predicted.eq(target_b).sum().float()).item()
        else:
            outputs = model(data)
            loss = criterion(outputs, target)
            _, predicted = outputs.max(1)
            total += target.size(0)
            correct += predicted.eq(target).sum().item()
        loss.backward()
        optimizer.step()
        if scheduler: scheduler.step()
        running_loss += loss.item()
        if (batch_idx + 1) % 100 == 0:
            print(f'  Epoch {epoch} - Batch {batch_idx + 1}: Loss={loss.item():.4f}, Acc={100.*correct/total:.2f}%')
    return running_loss / len(train_loader), 100. * correct / total


def evaluate(model, test_loader, criterion, device):
    """评估函数"""
    model.eval()
    test_loss, correct, total = 0.0, 0, 0
    with torch.no_grad():
        for data, target in test_loader:
            data, target = data.to(device), target.to(device)
            outputs = model(data)
            test_loss += criterion(outputs, target).item()
            _, predicted = outputs.max(1)
            total += target.size(0)
            correct += predicted.eq(target).sum().item()
    return test_loss / len(test_loader), 100. * correct / total


def main():
    print("=" * 60)
    print("开始 SVHN 深度学习实验")
    print("DenseNet-121 + CutMix + OneCycleLR")
    print("=" * 60)

    current_dir = os.path.dirname(os.path.abspath(__file__))
    project_root = os.path.dirname(current_dir)

    output_dir = create_date_output_dir(project_root)
    data_dir = os.path.join(output_dir, 'data')
    logs_dir = os.path.join(output_dir, 'logs')
    os.makedirs(data_dir, exist_ok=True)
    os.makedirs(logs_dir, exist_ok=True)

    batch_size, num_epochs, max_lr = 128, 1, 0.01
    device = get_device()

    train_transform = transforms.Compose([
        transforms.RandomCrop(32, padding=4),
        transforms.RandomHorizontalFlip(),
        transforms.RandomRotation(10),
        transforms.ColorJitter(brightness=0.2, contrast=0.2),
        transforms.ToTensor(),
        transforms.Normalize(mean=[0.4377, 0.4438, 0.4728], std=[0.1980, 0.2010, 0.1970])
    ])
    test_transform = transforms.Compose([
        transforms.ToTensor(),
        transforms.Normalize(mean=[0.4377, 0.4438, 0.4728], std=[0.1980, 0.2010, 0.1970])
    ])

    train_dataset = SVHN(root=data_dir, split='train', transform=train_transform, download=True)
    test_dataset = SVHN(root=data_dir, split='test', transform=test_transform, download=True)

    train_loader = DataLoader(train_dataset, batch_size=batch_size, shuffle=True, num_workers=0, pin_memory=True)
    test_loader = DataLoader(test_dataset, batch_size=256, shuffle=False, num_workers=0, pin_memory=True)

    model = SVHNDenseNet(num_classes=10).to(device)
    criterion = nn.CrossEntropyLoss()
    optimizer = optim.AdamW(model.parameters(), lr=0.001, weight_decay=1e-4)
    scheduler = optim.lr_scheduler.OneCycleLR(optimizer, max_lr=max_lr, epochs=num_epochs, steps_per_epoch=len(train_loader), pct_start=0.3)

    best_acc = 0.0
    start_time = time.time()

    for epoch in range(1, num_epochs + 1):
        train_loss, train_acc = train_one_epoch(model, train_loader, criterion, optimizer, device, epoch, scheduler)
        test_loss, test_acc = evaluate(model, test_loader, criterion, device)
        print(f"Epoch {epoch}: Train Loss={train_loss:.4f}, Train Acc={train_acc:.2f}%, Test Loss={test_loss:.4f}, Test Acc={test_acc:.2f}%")
        if test_acc > best_acc:
            best_acc = test_acc
            torch.save(model.state_dict(), os.path.join(logs_dir, 'best_model.pth'))

    print(f"\n训练完成! 最佳测试准确率: {best_acc:.2f}%")
    print(f"总训练时间: {time.time() - start_time:.1f}s")


if __name__ == '__main__':
    main()

d:\WorkPlace\ClaudeCode\2026-04-03_1/
├── data/                    # 数据集缓存
│   └── SVHN/
├── logs/                    # 训练日志和模型
│   ├── training_log_svhn_densenet121_cutmix_*.txt
│   └── svhn_densenet121_cutmix_best_model_*.pth
├── SVHN_DenseNet121_CutMix.py
└── SVHN_DenseNet121_CutMix_实验报告.md
